M15WM
- Capable of 1,450 lbs. of clamp force
- Designed to fit inside an 8″ - 10” diameter wheel
- Available as a complete system, aluminum caliper, ductile cast iron bracket, & hub/disc
- Simple single-piece caliper bridge design
- Choice of CW or CCW lever actuation
- Minimum moving parts to wear out
Vehicle Category:
Markets:
| Weight | 2.5 lbs. |
|---|---|
| Rotor Diameter | 6 in. to 8 in. |
| Rotor Thickness | 0.188 in. |
| Lining Type | Non-Asbestos Organic |
| Total Lining Area | 2.9 sq. in. |
| Usable Lining Thickness Per Pad | 0.125 in. |
